Advantages
1. API certified.
2. Truck mounted rig, compact and rugged design with high mobility.
3. Hydraulic top drive of this water well drilling equipment provides high torque and infinitely variable speed control.
4. Hydraulic feed system of our water well drilling machines offers precise control of weight on bit (WOB) and rate of penetration (ROP).
5. Pull-down drilling function negates the use of weighted drill string in top hole and directional drilling operations.
6. Tilting top drive provides fast, efficient pipe handling by picking up and laying out drill pipe horizontally.
7. No cranes are needed in the setup of this geotechnical drilling equipment due to the hydraulic self-erecting mast.
Features
1. Truck mounted.
2. Telescopic mast.
3. Two-speed top drive with hydraulic rough neck.
4. Tilting top drive.
5. 5 MT boom crane.
6. Premium hydraulic components from Europe / US.
After-sales Service
Our professional engineer team is globally available, 24/7.
Note
Choose the correct capacity;
BOP is optional;
Pipe handler is optional.
Technical Specifications
| Feed system | |
| Pulling Force | 60t |
| Pull Down Force | 14.5t |
| Slipbox | |
| Max Opening Diameter | φ711mm |
| Top Drive | |
| Torque/ Rotation | 17,000Nm@0-70rpm 8,500Nm@0-140rpm |
| Through-Hole Diameter | 76mm |
| Mast | |
| Mast Length | After telescopic:17.3m before telescope:11.5m |
| Top Drive Stroke | 11.6m |
| Rod & Casing | II (9.15m) |
| Dimensions | |
| Total Weight | 55t |
| Dimensions (L × W × H) | 11m × 2.5m × 4.3m |
| Power System | |
| Main Engine | Cummins QSZ13-C500-Ⅲ |
| Power | 500HP |
| Displacement | 13L |
| Truck Chassis | |
| Model | (HOWO) 8 × 4 |
| Engine | 276kW |
| Air/ Mud Line | |
| Pressure | 21MPa |
| Tube Core | 2" |
| Mud Pump | Optional |
| Air Compressor | Optional |
