Advantages
1. Truck mounted rig, compact and rugged design with high mobility.
2. Hydraulic top drive of this well drilling equipment provides high torque and infinitely variable speed control.
3. Hydraulic feed system of our water well drilling machines offers precise control of weight on bit (WOB) and rate of penetration (ROP).
4. Pull-down drilling function negates the use of weighted drill string in top hole and directional drilling operations.
5. No cranes are needed in the setup of the rig due to the hydraulic self-erecting mast.
Features
1. Truck mounted;
2. Telescopic mast;
3. Two-speed top drive with hydraulic rough neck.
4. Premium hydraulics from Europe / US.
After-sales Service
Our professional engineer team is globally available, 24/7.
Technical Specifications
| Feed System | |
| Pull Force | 40t |
| Pull Down Force | 14.5t |
| Slipbox | |
| Max. Opening Diameter | φ711mm |
| Top Drive | |
| Torque / Rotation | 17,000Nm 0-70rpm 8,500Nm 0-140rpm |
| Through-Hole Diameter | 89mm |
| Mast | |
| Mast Length | 10.5m |
| Top Drive Stroke | 7.6m |
| Rod & Casing | II (9.15cm) |
| Dimensions | |
| Total Weight | 20t |
| Dimensions (L × W × H) | 10.5m × 2.25m × 3m |
| Power System | |
| Main Engine | Cummins QSC8.3-CC260 |
| Power | 194KW |
| Displacement | 8.3L |
| Crawler Track | |
| Max Permissible Gradient | 25° |
| Travelling Speed | 1km/h |
| Air / Mud Line | |
| Pressure | 103Bar |
| Tube Core | 2" |
| Mud Pump | Optional |
| Air Compressor | Optional |
